Aircom Threaded Male Adapter
$15.09 – $71.51 PER SINGLE PIECE
Use the aluminum male threaded connection fittings to connect aluminum piping to a female NPT threaded connection. Pipe sizes 20mm (3/4″) to 80mm (3″).
- Description
- Additional information
Description
Aircom Threaded Male Adapter
Use the Aircom threaded male adapter to connect pipe to a threaded connection.
| Code | Ø | inch | qty / bag |
| QLMNMAL020048NPT | 20×1/2″ | 3/4″x1/2″ | 2 |
| QLMNMAL020068NPT | 20X3/4″ | 3/4″X3/4″ | 2 |
| QLMNMAL025068NPT | 25×3/4″ | 1″x3/4″ | 2 |
| QLMNMAL025088NPT | 25X1″ | 1″X1″ | 2 |
| QLMNMAL032108NPT | 32X1.1/4″ | 1.1/4″X1.1/4″ | 2 |
| QLMNMAL040128NPT | 40X1.1/2″ | 1.1/2″X1.1/2″ | 1 |
| QLMNMAL050168NPT | 50X2″ | 2″X2″ | 1 |
| QLMNMAL063168NPT | 63X2″ | 2 1/2″X2″ | 1 |
| QLMNMAL063208NPT | 63X2.1/2″ | 2 1/2″X2.1/2″ | 1 |
| QLMNMAL080208NPT | 80X2.1/2″ | 3″X2.1/2″ | 1 |
| QLMNMAL080248NPT | 80X3″ | 3″X3″ | 1 |
Quick Line Aluminum
A complete system of pipes and fittings in aluminum.
The fittings are made in painted, die-cast aluminum and are available in diameters:
20–25–32–40–50–63–80–110–168 & 220 mm
The entire range of threaded fittings is available with GAS or NPT thread.
Aircom systems pay for themselves.
5 main reasons:
- Eliminate Wasted Air and Leaks – Our components in aluminum, technopolymer and HIP guarantee superior, above-average performance.
- Modular Design – Flexibility of use and greater adaptability to the specific usage requirements.
- Expandability According to Requirements – The system grows with the plant.
- Easy, Rapid Installation – Reduction in labor costs and ease of intervention.
- Optimum, Constant Performance – Constant energy savings over time.
The Quick Line Aircom Piping System is an easy installation process, saving you time, energy and money. The aluminum construction supplies clean air and a product that does not corrode like traditional compressed air piping materials.
Additional information
| Weight | N/A |
|---|---|
| Diameter | 3/4" or 20mm, 1" or 25mm, 1 1/4" or 32mm, 1 1/2" or 40mm, 2" or 50mm, 2 1/2" or 63mm, 3" or 80mm |
| NPT Thread | 1/2", 3/4", 1", 1 1/4", 1 1/2", 2", 2 1/2", 3" |
| Aircom Series | Quick Line Aluminum |
