Aircom Aluminum Tee Reduction
$34.52 – $133.10 PER SINGLE PIECE
Aircom Aluminum Tee Reduction is used to make a reducing connection from 20, 25, 40, 50 or 63mm pipe down to a drop of 20 or 25mm.
- Description
- Additional information
Description
Aircom Aluminum Tee Reduction
| Code | Ø | inch | qty / bag |
| QLTRAL025020 | 25X20 | 1″x3/4″ | 2 |
| QLTRAL032020 | 32X20 | 1.1/4″x3/4″ | 2 |
| QLTRAL040020 | 40X20 | 1.1/2″x3/4″ | 1 |
| QLTRAL040025 | 40X25 | 1 1/2″x1″ | 1 |
| QLTRAL050020 | 50X20 | 2″x3/4″ | 1 |
| QLTRAL050025 | 50X25 | 2″x1″ | 1 |
| QLTRAL063020 | 63X20 | 2.1/2″x3/4″ | 1 |
| QLTRAL063025 | 63X25 | 2.1/2″x1″ | 1 |
Quick Line Aluminum
A complete system of pipes and fittings in aluminum.
The fittings are made in painted, die-cast aluminum and are available in diameters:
20–25–32–40–50–63–80–110–168 & 220 mm
The entire range of threaded fittings is available with GAS or NPT thread.
Aircom systems pay for themselves.
5 main reasons:
- Eliminate Wasted Air and Leaks – Our components in aluminum, technopolymer and HIP guarantee superior, above-average performance.
- Modular Design – Flexibility of use and greater adaptability to the specific usage requirements.
- Expandability According to Requirements – The system grows with the plant.
- Easy, Rapid Installation – Reduction in labor costs and ease of intervention.
- Optimum, Constant Performance – Constant energy savings over time.
Use the Aluminum Manifold Female Threads With Drain on the 20 or 25mm drop pipe to connect a coupler and point of use tools or equipment.
Additional information
| Weight | N/A |
|---|---|
| Diameter | 1" or 25mm, 1 1/4" or 32mm, 1 1/2" or 40mm, 2" or 50mm, 2 1/2" or 63mm |
| Outlet | 3/4", 1" |
| Aircom Series | Quick Line Aluminum |
