Aircom FRL Series Compressed Air Lubricator

Price range: $46.47 through $99.88 PER SINGLE PIECE

SKU: N/A Category: Air Treatment

Description
Additional information

Description

Aircom FRL Series Compressed Air Lubricator

FRL Series Compressed Air Lubricator (1/4″ & 1/2″ NPT)

The FRL Series Compressed Air Lubricator supplies controlled, continuous lubrication to air-driven tools, pneumatic cylinders, air motors, and valves. Available in standard 1/4″ and 1/2″ NPT port sizes, this micro-fog lubricator introduces a fine mist of oil into the air stream proportional to air flow, reducing internal friction, preventing seal dry-out, and extending the operational lifespan of downstream pneumatic equipment.

Technical Specifications

Feature	1/4″ NPT Model	1/2″ NPT Model
Series	FRL Series Modular Air Preparation	FRL Series Modular Air Preparation
Port Size	1/4″ NPT	1/2″ NPT
Lubricator Type	Micro-Fog Atomizing	Micro-Fog Atomizing
Max Supply Pressure	145 PSI (10 Bar)	145 PSI (10 Bar)
Max Flow Capacity	Up to 28 CFM	Up to 110 CFM
Operating Temperature	41°F to 140°F (5°C to 60°C)	41°F to 140°F (5°C to 60°C)
Recommended Oil	ISO VG32 / Non-detergent pneumatic oil	ISO VG32 / Non-detergent pneumatic oil
Bowl Reservoir	Polycarbonate with steel guard	Polycarbonate with steel guard

Key Features & Benefits

Micro-Fog Delivery System: Atomizes oil into ultra-fine airborne particles that travel farther through piping and reach internal tool components without pooling or clogging lines.
Proportional Oil Feed: Automatically adjusts oil mist volume based on air demand, ensuring consistent lubrication whether running low-flow tools or heavy-duty machinery.
Precision Adjustment Drip Dome: Transparent sight-feed dome with an adjustable needle valve allows precise monitoring and regulation of the drip rate (drops per minute).
Dual Port Size Options:
- 1/4″ NPT: Engineered for point-of-use drops, compact air tools, small air cylinders, and light-duty assembly lines.
- 1/2″ NPT: Built for high-flow main feed lines, heavy industrial machinery, large air motors, and multi-tool stations.
In-Line Refilling & Impact Guard: Transparent polycarbonate bowl housed inside a rigid steel bowl guard allows 360-degree oil level monitoring; refillable under pressure without interrupting main air line operation.
Modular FRL System Compatibility: Pairs seamlessly with FRL Series particulate filters and pressure regulators using standard modular joiner brackets.
